Distribution box, surface mounted, without door, 2 row for 24+4 poles, colour: white
Distribution box surface mounted, IP40, 63A, 400VAC, without door, with terminal block for PE and N terminal 2×13, as well as necessary accessories (DIN rail, covers, installation material), 2-row for 24+2 poles, colour: white
| Characteristic | Value |
|---|---|
| Article Nr | 344612008 |
| PU | 1 |
| EAN | 4008224610964 |
| Extension possible | no |
| Number of rows | 1 |
| Type of cover | None |
| Type of closure | not applicable |
| Cover model | With notch |
| Width | 250,0 mm |
| Width in number of modular spacings | 14 |
| DIN-rail | yes |
| EMC-version | no |
| Earthing terminal block | yes |
| Colour | White |
| Height | 353,0 mm |
| With mounting plate | no |
| With lock | no |
| Mounting method | Surface mounted |
| Neutral terminal block | yes |
| RAL-number | 9003 |
| Degree of protection (IP) | IP40 |
| Signal passing door | no |
| Depth | 70,0 mm |
| Transparent cover/door | yes |
| Material housing | Plastic |
| Netzstecker - Typbezeichnung | ohne |
