HK07 – room thermostat “changeover”, 1100W, colour: anthracite
HK07 – room thermostat “changeover”, temperature range 5°C to +30°C, night setback 4 Kelvin, switch-off of the heater when the setpoint temperature is exceeded and activation of a cooling system, 5(2)AX, nominal voltage 250V~, 1100W, combinable with switch range HK07, colour: anthracite
| Characteristic | Value |
|---|---|
| Article Nr | 290415003 |
| PU | 1 |
| EAN | 4008224661324 |
| Connection | 3-wire |
| Number of heater outputs | 1,00 |
| Number of cooler outputs | 1 |
| Number of modules (module system) | 1 |
| Type of power supply | 230 V AC |
| Model | on/off |
| Sensor/feeler type | Bimetal |
| Operation | Turn |
| Width | 71,0 mm |
| Adjustable differential | nein |
| Differential value | ,00 – ,50 K |
| Diameter | 71,0 mm |
| Explosion-proof | no |
| Colour | anthracite |
| Farbe (Kopp-Bezeichnung) | anthrazit |
| Suitable for heating | ja |
| Suitable for cooling | ja |
| Height | 71,0 mm |
| IFTTT support available | no |
| Class of the temperature control | II |
| Compatible with Amazon Alexa | no |
| Compatible with Apple HomeKit | no |
| Compatible with Google Assistant | no |
| Contact type | Change-over contact (NO/NC) |
| Max. contact load | 5,00 A |
| Max. contact voltage | 250,00 V |
| Measuring range | 5 – 30 °C |
| With display | no |
| With receiver | no |
| With sound indicator | nein |
| With tap water circuit | nein |
| Mounting method | Flush mounted (plaster) |
| RAL-number | 7024 |
| Control characteristic | P |
| Degree of protection (IP) | IP20 |
| Degree of protection (NEMA) | Other |
| External sensor | nein |
| Temperature readable | nein |
| Thermal feedback | ohne |
| Depth | 41,8 mm |
| Concealed operation | no |
| Netzstecker - Typbezeichnung | ohne |
